Carport Avanti
A steel carport for one car
Carport Avanti is a free-standing steel structure for one vehicle. The four posts are set back and reinforced with diagonal braces, so the front side has no posts. The smooth roof with a pitch of about 1.5° directs rainwater into the built-in gutter.
Galvanised and powder-coated steel in anthracite is protected against rust. Under the 5.3 x 3.2 m roof you can park one passenger car.
Galvanised and powder-coated steel
The posts, beams and roof panels are made of steel that is first galvanised and then powder-coated in anthracite. Galvanised and powder-coated steel is protected against rust. Diagonal braces connect the posts to the beams; the structure is designed for wind of up to 90 km/h.
A smooth pitched roof with a gutter
The steel panel roof is laid with a pitch of about 1.5°, so water and snow slide towards the lower edge. There they are caught by the built-in gutter, which directs rainwater to one side.
Fixed to the base
Four steel posts are fixed to a solid base, a concrete slab or point foundations. The kit for fixing the carport to the ground is included, with four anchor bolts supplied for each post.
Technical data
External dimensions including roof530 x 321 x 226 cm
Total weightapprox. 275 kg
Wind resistance90 km/h
Snow load50 kg/m²
Dimension overviewCarport dimensions
Frequently asked questions
Which vehicles is it suitable for?
How much snow and wind does it take?
Where does the water drain to?
What base do I need?
Can I assemble it myself?
What about the warranty and maintenance?
Technical Specifications
| Width | 3.21 m |
| Depth | 5.3 m |
| Height | 2.26 m |
| Weight | 320 kg |
| Snow load | 50 kg/m² |
| Wind resistance | 90 km/h |
Carport Avanti: a steel structure for one passenger car, a front side without posts, a pitched roof with a gutter and steel protected against rust. Delivery is free and the structure comes with a 5-year warranty.
